Product features
The insulation and repair sleeves of the TE Raychem product line extend the service life of cables and assemblies that are heavily stressed, especially in high-temperature applications, and offer additional protection against moisture, corrosion, and mechanical stress. With an additional layer of durable heat shrink tubing, the insulation and repair sleeves of the TE Raychem product line provide heavily stressed cables and assemblies with protection against water ingress as well as mechanical protection from wear and tear. Available in different high-temperature ranges and sizes, the sleeves cover damaged areas allowing extended service life as expensive circuitry does not need to be replaced immediately.
Filter
| Amount | Item No. | Description | On stock | EAN | Total length after shrink | Inner diameter finger before shrink | Inner diameter finger after shrink | Operation temperature | VE | Unit |
|---|---|---|---|---|---|---|---|---|---|---|
|
|
AT099-35 | 010951-000 |
|
50mm | 12.2mm | 6.4mm | -75 - 150°C | 20 | Stk | |
|
|
AT099-19 | 054431-000 |
|
7611971023115 | 50mm | 8mm | 3.2mm | -75 - 150°C | 10 | Stk |
|
|
AT099-42 | 232723-000 |
|
7611971023139 | 40mm | 18.49mm | 9.5mm | -75 - 150°C | 20 | Stk |
|
|
AT099-51 | 247265-000 |
|
50mm | 25mm | 12.8mm | -75 - 150°C | 20 | Stk | |
|
|
AT099-34 | 293761-000 |
|
40mm | 12.2mm | 6.4mm | -75 - 150°C | 20 | Stk | |
|
|
AT099-43 | 341263-000 |
|
40mm | 18.5mm | 9.5mm | -75 - 150°C | 20 | Stk | |
|
|
AT099-18 | 619547-000 |
|
7611971023108 | 40mm | 8mm | 3.2mm | -75 - 150°C | 20 | Stk |
|
|
AT099-10 | 620229-000 |
|
40mm | 5.6mm | 2.4mm | 150 - 225°C | 20 | Stk | |
|
|
AT099-26 | 751921-000 |
|
7611971023122 | 40mm | 10mm | 4.8mm | -75 - 150°C | 20 | Stk |
|
|
AT099-20 | 766867-000 |
|
60mm | 8mm | 3.2mm | -75 - 150°C | 20 | Stk | |
|
|
AT099-50 | 835601-000 |
|
40mm | 25mm | 12.8mm | -75 - 150°C | 20 | Stk |
